3LSF SERIES ( BARE PUMP)

หมวดหมู่สินค้า: EBARA PUMP
ปั๊มน้ำหอยโข่งสแตน BARE PUMP STAINLESS STEEL 316L
ติดต่อสอบถามเพิ่มเติม : 061-075-5537

แท็ก: EBARA3LSF3LSF-323LSF-403LSF-503LSF-65

20 กันยายน 2567

ผู้ชม 11 ผู้ชม







Model

 Motor





Phase

 Flow (m3/hr)



HP



kW

 100 150 200 300 333 360 400 450
6 9 12 15 18 20
Head (m)
3LSF-32-125/1.1 1.5 1.1 220V/380V 21 20 18.5 17 15 13
3LSF-32-160/1.5 2.0 1.5 220V/380V 28 26.5 24.5 22 19 17
3LSF-32-160/2.2 3.0 2.2 220V/380V 35.5 34.5 32.5 30.5 27.5 25.5
3LSF-32-200/3.0 4.0 3.0 380V 42 41 38.5 35 31.5 29
3LSF-32-200/4.0 5.5 4.0 380V 53.5 51.5 49.5 43.5 40.5 38
3LSF-32-200/5.5 7.5 5.5 380V 69 67.6 65 58.3
3LSF-32-200/7.5 10 7.5 380V 69 67.6 65 58.3 55.5 53 49 44







Model

 Motor





Phase

 Flow (m3/hr)



HP



kW

 200 300 333 360 400 450 500 600 700
12 15 18 20 24 27 30 33 36
Head (m)
3LSF-40-125/1.5 2.0 1.5 220V/380V 19 17.5 17 16.5 15.7 14.5 13.2 10.3 7
3LSF-40-125/2.2 3.0 2.2 220V/380V 25.5 24 23.5 23 22 21 19.5 16.4 13
3LSF-40-160/3.0 4.0 3.0 380V 29.5 27.5 27 26.5 25.5 24 22.5 20 17
3LSF-40-160/4.0 5.5 4.0 380V 38.5 37 36 35.5 34.5 33 32 29 25.5
3LSF-40-200/5.5 7.5 5.5 380V 45.5 44 43 42.5 41 39.5 38 35 31
3LSF-40-200/7.5 10 7.5 380V 57 55.5 55 54.5 53.5 52.5 51 47.5 44
3LSF-40-200/11 15 11 380V 71 70 70 69.5 68.5 67.5 66 63 59







Model

 Motor





Phase

 Flow (m3/hr)



HP



kW

  400 450 500 600 700   800  1000  1200
24 27 30  33 36  39   42 48
Head (m)
3LSF-50-125/2.2   3.0  2.2  220V/380V  17.5 17  16.3  14.9   13.4 11.7   8
 3LSF-50-125/3.0 4.0  3.0   380V 20.5  20  19.6  18.4  17 15.4  11.8   8
 3LSF-50-125/4.0  5.5  4.0   380V 26  25.5  25  24  22.5 21.5  17.9  14
 3LSF-50-160/5.5 7.5  5.5  380V  31  30.5  30  28.5   27 25.5  22  18
 3LSF-50-160/7.5 10  7.5   380V 38.5  38  37.5  36  35 33.5  30  26
 3LSF-50-200/9.2 12.5 9.2   380V     50  49  47.5 45.5  40.5  34
 3LSF-50-200/11 15  11   380V     56  55  54 52  48  42
 3LSF-50-200/15 20  15   380V     70  69  68 66  62  57







Model

 Motor





Phase

 Flow (m3/hr)



HP



kW

 600 700 800 1000 1200 1500 1800 1900
36 42 48 60 72 90 108 114 120 126 132
Head (m)
3LSF4-65-200/2.2 3.0 2.2 380V 12.4 11.7 10.8 8.8
3LSF-65-125/4.0 5.5 4.0 380V 20 19.4 18.5 16.5 14.3 10.7 7
3LSF-65-125/5.5 7.5 5.5 380V 25 24.5 23.5 21.5 19.1 15.5 11.7 10.4
3LSF-65-125/7.5 10 7.5 380V 30.5 29.5 29 27 24.5 21 16.8 15.4 14
3LSF-65-160/7.5 10 7.5 380V   30 29 27 25.5 21.5 17.5 16 14.5
3LSF-65-160/9.2 12.5 9.2 380V   34.5 34 32 29.5 26 21.5 20 18.6 17
3LSF-65-160/11 15 11 380V   38.5 38 36 34 30.5 26 24.5 23 21.5 20
3LSF-65-160/15 20 15 380V   45.5 45 43 41 37.5 33.5 32 30.5 29 27
3LSF-65-200/15 20 15 380V   51 50 48 45.5 41 36 34 32 30
3LSF-65-200/18.5 25 18.5 380V   58.5 57.5 55.5 53 49 44 42.5 40.5 39 37
3LSF-65-200/22 30 22 380V   65.5 65 63 60.5 56.5 52 50.5 48.5 47 45
